Buttwelding Pipe fittings

GV02-MSS SP-85 MSS SP-85 125LB Globe Valve

Technical Specification:

Size: DN40-DN300

Pressure:SP-85 125LB

Design:MSS SP-85

Face to Face: ANSI B16.10

Flanges:EN1092-2 PN16

Hydraulic test: MSS SP-85

Seat Test:13.8bar

Shell Test:24.1bar

GV01-DIN3356 F1 DIN3202 F1 PN16 Globe Valve

Technical Specification:

Size: DN40-DN300

Pressure:F1 PN16

Design:DIN3356

Face to Face: DIN3202 F1

Flanges:EN1092-2 PN16

Hydraulic test: ISO 5208

Seat Test:17.6bar

Shell Test:24bar

C95800 gate valve

BALL VALVE 1

DIN Gate Valve PN16

Technical Specification:

Size: DN50-DN1200

Pressure: PN10-PN250

Material: 1.0619, 1.1138, 1.4306, 1.4308, 1.4408, 1.7706

API Gate Valve 150LB

Technical Specification:

Size: 2″- 48″

Pressure: Class150-Class1500

Material: WCB,LCB,LCC,WC6,WC9,C12,CF8,CF8M,CF3,CF3M

BFV01-DIN3202 DIN BUTTERFLY VALVE BOTH WAFER AND LUG TYPE

Technical Specification:

Size: DN40-DN600

Pressure: BFV01-DIN3202

Design: DIN3202

Face to face:DIN3202 K1

Flange Drilling:EN1092-2

Mounting pad:ISO5211

Inspection and Test:API598

Seat Test: 17.6bar

Shell Test: 24bar

EJ01-Fland End Expansion Joint Flange End

Technical Specification:

Size: DN32-DN600

Pressure:EJ01-Fland

Working Pressure:1.6Mpa (16kg/CM²)

Breaking Pressure:4.8Mpa(48kg/CM²)

Temperature:-20℃ to+115℃

Application:Fresh Water,Sea Water,Hot Water,Air and Gas

Strainer 01-Y Type Y Strainer flange end

Technical Specification:

Size: DN15-DN400

Pressure: 01-Y Type

Face to Face:DIN3202 F1

Flanges:EN1092-2 PN16

Hydraulic test:ISO 5208

Seat Test: 17.6bar

Shell Test: 24bar
